MSE-2112-X2Y2-L09-C1

MSE防尘微动开关(弹片式)

MSE series Dustproof Micro Switch (Leaf Spring Type)

产品描述Product description

◆MSE系列是一-款专用型的微动开关 ，装上防尘罩后具有防尘功效 ，适用于种种手持电动工具和园林工具 ，如：砂光机、拋光机、100和125角磨机、小圆锯、小型斜切锯(介铝机)、电动喷枪、打草机 ，电链锯等。
◆ MSE series are one special type micro switches, with dustproof function when employ protection cap, commonly for used in portable power-tools and gardening tools, such as Sanders,Polisher Grinders, 100mm and 125mm Small Angle Grinders,Small Circular Saws, Small Miter Saws, Electric Sprayers, Grass Trimmers, Electric Chain Saws, etc.

产品特征Features

◆可选附带以下功效 Optional with the function as follows:
→单极�？� SPNO (Single Pole Normally Open)
→单极常闭 SPNC (Single Pole Normally Close)
→单极常闭�？� SPCO (Single Pole Close and Open)
→双极�？� DPNO (Double Pole Normally Open)
→双极常闭 SPNC (Double Pole Normally Close)
→双极常闭�？� SPCO (Double Pole Close and Open)
◆可选附带以下附件 Optional with the accessories as follows:
→压柄 Handle
→防护罩 Protection Cap

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥5E4/1E5
→电气耐久寿命 Electrical life endurance≥1E4/5E4
→最大攻击电流 Max. Inrush current at 250V60A
→最大攻击电流 Max. Inrush current at 127V96A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M  Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature (ENEC/UL)-25°C~125C
→情况温度 Ambient temperature (TOV/ CQC)0°C~85°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP60
→适用于II类防护器具 Suitable for appliances of protection class II
→开关操作力选择规模 Operating force range3N~15N
→开关内部触点间隙Contact gap range0.8~2.5mm

端子类型Terminals

◆COM, NO, NC端子 Terminals:
→插片端子 Plug-in terminals 4.8×0.8mm
→插片端子 Plug-in terminals 4.8×0.5mm
→焊接端子 Solder terminals
★本产品荣获实用新型专利 ，专利号：ZL201920124632.7
★Utility Model patented with the no. is ZL201920124632.7

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
